YOU WON'T KNOW UNLESS YOU GO
Of course you're not lost, you just aren't quite sure if this road is the quickest route to the next ridge. The weather is great, you've got all day and you're riding Terra, so keep the wheels rolling. If route-finding, taking the long way home, and straying from the beaten path are your ideas of fun, there is no better tool than Terra for unlocking your desire to explore.
All Road Geometry
- Control in a variety of circumstances. Terra is designed to be at home on dirt, gravel, or just about anything else you might encounter.
- Terra ergonomics work for cyclocross, all-day rides, and the occasional long training day on the road.
- Handling is precise and intuitive. Angles and dimensions are considered carefully across a range of sizes to maximize rider comfort.
- Terra can fill several roles—Gravel, Road, CX, Winter Training, or Commuting. Tire Clearance and the ability to mount accessories like mudguards, combined with a functional All-Road Geometry, means that Terra can change with the seasons.
|Frame||Orbea Terra Hydro disc, hydroformed triple butted aluminium, tapered 1-1/8" - 1.5", BB 68mm – BSC English, Thru Axle 12mm x 142mm rear, thread M12x P1.5, DT internal cable routing, 27.2mm seat tube, MMS system|
|Fork||Orbea Terra OMP carbon disc fork, full carbon steerer, tapered 1-1/8" - 1.5", carbon dropouts Thru axle 12mm x 100m, thread M12xP1.5, MMS system|
|Headset||FSA 1-1/8 - 1-1/2" Integrated Carbon Cup ACB Bearings|
Front: Orbea Thru Axle 12x100mm M12xP1.5 Hollow
Rear: Orbea Thru Axle 12x142mm M12xP1.5 Hollow
|Hubs||Shimano RS470 28H|
|Tires||Vittoria Terreno Dry Gravel G2.0 TNT 700x38c|
|Crankset||Shimano GRX RX600 40t|
|Chain||Shimano HG 601|
|Rear Derailleur||Shimano RX812 GS|
|Cassette/Rear Cogs||Shimano SLX M7000 11-40t 11-Speed|
|Handlebars||OC1 All Road, reach 80mm, drop 125mm, flare 12º|
|Stem||OC1 31.8mm interface -6º|
|Brakes||Shimano RX400 Hydraulic disc|
|Saddle||Selle Royal Seta RS|
|Seat Post||OC2 27.2 Offset 20|
* Subject to change without notice.
|Military Green / XX-Small||08434446766916||L11146BL|
|Military Green / X-Small||08434446766947||L11149BL|
|Military Green / Small||08434446766978||L11152BL|
|Military Green / Medium||08434446767005||L11155BL|
|Military Green / Large||08434446767036||L11158BL|
|Military Green / X-Large||08434446767067||L11161BL|
|Light Green / XX-Small||08434446766923||L11146BM|
|Light Green / X-Small||08434446766954||L11149BM|
|Light Green / Small||08434446766985||L11152BM|
|Light Green / Medium||08434446767012||L11155BM|
|Light Green / Large||08434446767043||L11158BM|
|Light Green / X-Large||08434446767074||L11161BM|
|Black / XX-Small||08434446766909||L11146BK|
|Black / X-Small||08434446766930||L11149BK|
|Black / Small||08434446766961||L11152BK||210000004567|
|Black / Medium||08434446766992||L11155BK|
|Black / Large||08434446767029||L11158BK|
|Black / X-Large||08434446767050||L11161BK|
